Dimensions 162 x 84 x 37 mm (6.38 x 3.31 x 1.46")
Weight 250 g (8.81 oz)
Enclosure Characteristics Outdoor UV Stabilized Plastic
Processor MIPS 74Kc
Memory 128 MB DDR2 SDRAM, 16 MB NOR FLASH
Networking Interface (1) 10/100/1000 Mbps
RF Connections (2) RP-SMA (Waterproof )
LEDs Power, Ethernet, (4) Signal Strength
Max. Power Consumption 8.5W
Power Supply 24V, 0.5A Gigabit PoE Adapter
Power Method Passive PoE (Pairs 4, 5+; 7, 8 Return)
ESD/EMP Protection ± 24KV Air / Contact
Operating Temperature -40 to 80° C (-40 to 176° F)
Operating Humidity 5 to 95% Noncondensing
Shock and Vibration ETSI300-019-1.4
R5AC-Lite Software Information
Modes Access Point, Station
Services Web Server, SNMP, SSH Server, Telnet , Ping Watchdog, DHCP, NAT, Bridging, Routing
Utilities Antenna Alignment Tool, Discovery Utility, Site Survey, Ping, Traceroute, Speed Test
Distance Adjustment Dynamic Ack and Ackless Mode
Power Adjustment Software Adjustable UI or CLI
Security WPA2 AES Only
QoS Supports Packet Level Classification WMM and User Customer Level: High/Medium/Low
Statistical Reporting Up Time, Packet Errors, Data Rates, Wireless Distance, Ethernet Link Rate
Other
Remote Reset Support, Software Enabled/Disabled, VLAN Support, 256QAM,
20/40/50/60/80 MHz Channel Width Support
Ubiquiti Specific Features
50 MHz Channels, airMAX Mode, Traffic Shaping with Burst Support,
Discovery Protocol, Frequency Band Offset, Ackless Mode
Operating Frequency
Worldwide: 5150 - 5875 MHz
USA: 5725 - 5850 MHz
Output Power 27 dBm
